T5 vs T8 vs T12 Tubes – What’s the Difference?

 Introduction

When upgrading or replacing fluorescent tubes with LED tubes, youll notice certain specifications in the fixtures: T5, T8, and T12. These numbers aren’t arbitrary—they relate to the fixtures efficiency and compatibility. Today, Toppo Lighting will explain the differences between these LED linear lights to help you find the most suitable option.



What Does "T" Stand For?

In LED lighting, the "T" stands for "Tubular," referring to the shape of the tube. The number indicates the tube’s diameter, measured in eighths of an inch:


 T12 Tube: 12/8 inches in diameter (1.5 inches)

 T8 Tube: 8/8 inches in diameter (1 inch)

 T5 Tube: 5/8 inches in diameter (0.625 inches)

These different diameters affect light distribution patterns. Larger tubes produce a wider beam, while slimmer tubes offer more focused lighting.


Comparison of T5, T8, and T12 LED Tubes

Comparison

T12 LED Linear Tube

T8 LED Tube

T5 LED Linear Tube

Diameter

1.5 in (12/8")

1 in (8/8")

0.625 in (5/8")

Power (vs. Fluorescent)

18-20W (replaces 34W fluorescent)

14-18W (replaces 32W fluorescent)

10-14W (replaces 28W fluorescent)

Light Output

1900-2200 lumens

2000-2400 lumens

1800-2200 lumens

Efficiency (lm/W)

Medium (~90-110 lm/W)

Higher (~110-130 lm/W)

Highest (~130-160 lm/W)

Fixture Compatibility

Only fits T12 or requires adapter for T8

Directly fits T8; some can be modified for T5

Requires dedicated T5 fixtures

Ballast Requirement

Compatible with old magnetic ballasts or bypass

Usually requires electronic ballast or bypass

Mostly direct drive (no ballast needed)

Best For

Retrofitting old T12 fixtures; low-usage areas

Mainstream commercial/industrial upgrades; cost-effective

New high-efficiency lighting; compact spaces

CRI (Color Rendering Index)

80+

80-90

85-95 (premium models can exceed CRI>90)



How to Decide?

Beyond the above details, consider these factors when choosing:

 Existing Infrastructure: If youre not planning a full lighting system upgrade, check whether your current fixtures support the new LED tubes.

 Usage Patterns: For high-usage areas like retail displays or task lighting, we recommend more energy-efficient T5 tubes.

 Light Quality Needs: If you want the best balance between efficiency and light output, T8 LED tubes are a great choice.


Conclusion

T8 LED tubes are widely used for most lighting applications due to their strong performance. However, T5 tubes are better suited for energy savings or space-constrained environments, while T12 tubes are mainly for retrofitting old fixtures.

Toppo believes understanding these differences will help you make the right choice. Based on your needs, we also offer high-CRI, energy-efficient T5 & T8 linear tubes, as well as customized LED lighting solutions to upgrade your commercial and workspace lighting. Contact us for professional support.
